The REX Vineyard series has been designed for true professionals. It mounts fluid-cooled 3 and 4-cylinder Perkins engines that offer high performances in terms of power, engine torque and torque reserve and which, along with tried and tested reliability, represent the prime features of the range. The modular transmissions, which reflect the LANDINI philosophy, are simple and reliable, but their main feature is the low power draw typical of mechanical transmissions. The gearbox has a synchronized reverse shuttle, 3 ranges where the options are the Overdrive, to race along at 40 kph, the Underdrive to reduce each ratio by 20% and the Creeper to obtain a 300 m/h ground speed (-80% of all ratios). The all-out width of the "narrow" REX V version is only 980 mm with 28" tyres for both PLAT and CAB types while the hydraulic circuit with single or double pump makes REX V "top of the class" when it comes to performance and versatility since up to 8 auxiliary control valves can be mounted.
Rex V |
60V |
65V |
70V |
80V |
Engine (Green) |
||||
Direct-injection Perkins engine |
903-27 |
903-27T |
1004-40 |
1004-42 |
Displacement/nr. of cylinders |
cc 2700/3 |
cc 2700/3turbo |
cc 3990/4 |
cc 4233/4 |
Max. power DIN |
54/40 |
64/47 |
67/49 |
78/57 |
Max. power ISO |
55/40,5 |
65/48 |
68/50 |
80/58,5 |
Transmission |
||||
Reverse shuttle+base gearbox: 2FWD+12REV |
STD |
OPT |
OPT |
OPT |
Reverse shuttle + Overdrive:24FWD+12REV(40 Km/h) |
OPT |
STD |
STD |
STD |
Hydraulic power lift |
||||
Std lifting power |
2600 |
2600 |
2600 |
2600 |
Weigths and dimensions (rear tyres) |
||||
Min / max. all out width |
1223 |
1223 |
1223 |
1223 |
Weight 4WD |
2650 |
2650 |
2800 |
2800 |
