The VISION series is compact in size, essential for breeders who need to use their tractors in the stalls and outside. With a maximum length of 4,430 mm, an all-out minimum width of 1,850 mm (13.6-38" tyres) and a height of 2,565 mm (VISION 85 with 16.9-30" tyres), VISION is the ideal tractor for all animal husbandry uses. The new cab with its all-round visibility, modern heating and ventilating system and central air conditioning system allows operators to work with ease, moving inside and outside the animal housings without impediments. The capacity of the hydraulic pump increases the versatility of VISION tractors, always quick, precise and powerful when front loaders are used to shift forage crops. The transmission has been designed to boost the efficiency of the two-speed hydraulic PTO (540/540E or 540E/1000) and operates in a proportional way to the ground speed of the tractor when trailers are hitched with the interchangeable shaft (with 6 or 21 splines) in the Turbo versions.



Vision	85 speed five-power shuttle	95 speed five-power shuttle	105 speed five-power shuttle
Direct-injection Perkins engine (Euro2/tier2)	1104C-44	1104C-44T	1104C-44T
Displacements / N° of cylinders	cc 4400/4	cc 4400/4	cc 4400/4
Turbo charged	no	yes	yes
net pto power ISO	hp/kw 75.5/55.5	hp/kw 85/62.5	hp/kw 91/67
Max power ISO	hp/kw 81.6/58,5	hp/kw 91.9/67.6	hp/kw 98.6/72.5
SpeedFive + creeper +mech. reverse shuttle 20fwd+20rev	STD - N/A	STD - N/A	STD - N/A
speedfive + creeper 20fwd+20rev	N/A - STD	N/A - STD	N/A - STD
powerfive + speedfive + creeper 40fwd+40rev	N/A - OPT	N/A - OPT	N/A - OPT
reverse power shuttle: reverse power shuttle under load	N/A - STD	N/A - STD	N/A - STD
mechanically operated lift	STD	STD	STD
electronically operated lift "landtronic	N/A - OPT	N/A - OPT	N/A - OPT
Lifting power width 2 additional cylinders kg	2600 STD - 3700 OPT	3700	4350
Total weight (without ballasts)	kg 4070	kg 4070	kg 4160
Total lenght with ballasts	mm 4430	mm 4430	mm 4440
Wheelbase	mm 2380	mm 2380	mm 2410

The VISION series features 4-cylinder Perkins engines that comply with EURO standards, they offer high performances in terms of power, engine torque and torque reserve (up to 25%) and which, combined with tried and tested reliability, make these tractors ideal for open field work. The modular transmissions, which reflect the LANDINI philosophy, are simple and reliable, but their main feature is the low power draw . They are perfect for jobs requiring ground speeds lower than 300 m/h, obtainable with the Creeper. The Reverse Power Shuttle is option, such us Hi-Lo Powershift. The 44 Kg/HP weight/power ratio is optimal and ensures the utmost efficiency on the ground. The track width can be adjusted between 1,400 and 2,000 mm. Along with the 4,350 Kg lifting capacity, these features make the VISION range the most conventional tractors in the under 100 HP power bracket.
